Complete Reliability
Magneto Electric has been building and repairing transformers in Toronto for over 70 years. With excellent service and industry-leading expertise, we provide solutions that will power your business for years to come. Quality is guaranteed. Our company is ISO 9001:2015 certified.
CSA Certification
All dry-type transformers are designed, built and tested to CSA C9 M1981 standards and are certified to CSA standards C22.2 No. 47-M90 up to 12 MVA, 34.5 kV Class, 150 kVBIL. Liquid-filled transformers are designed, built and tested to CSA standards C227.2, C227.4, C2, C88 up to 20 MVA, 72.5 kV Class, 350 kVBIL.
Same Day Emergency Service
We understand the need for quick solutions. If you’re facing an emergency situation, we can be there on the same day you call.
Product Specs / Details
- Dry-Type Power Transformers
- Up to 15 MVA, 46 kV class (substation or standalone)
- Vacuum varnish impregnated coils
- Vacuum epoxy impregnated coils
Dry-Type Station Service Transformers
- Up to 750 kVA, 34.5 kV Class, 140 kVBIL
Liquid-Filled Power Transformers
- Up to 20 MVA, 72.5 kV class, 350 kVBIL
- Mineral oil, R-Temp fluid, silicone fluid
Liquid-Filled Distribution Transformers
- Up to 3000 kVA, 34.5 kV class, 200 kVBIL
Integrated Outdoor Substations
- Up to 5 MVA
- Tamperproof, liquid-filled transformer, HV-fused load break switch
Specialty & Custom Transformers
- Rectifier – up to 7000 kVA, 27.6 kV (substation or standalone)
- Motor-starting auto – 5 & 15 kV, up to 30,000Hp
- Drive-isolation – up to 15 kV, 300-2000 Hp
- Exciter – generator excitation
- Traction duty – up to 7400 kVA, 27.5 kV / phase-shifted, delta wye, harmonic elimination
- Super isolation – normal and common noise attenuation to 180 dBA
Rewinds, Repairs, Rebuilds & Retrofits
Magneto Electric offers solutions for any transformer challenge. Our expert service team provides on-site repair, rewinds, rebuilds and retrofitting services for dry and liquid-filled transformers, including:
- Replacing radiators for liquid-filled transformers
- Assembling dry-type transformers and replacing coils
- Replacing cast-coil transformers for VPI dry-type transformers
- Upgrading capacities for all transformer types
- Seamless retrofitting of transformers to existing equipment within available space and very little downtime
